FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 11 of 92 2022-10-07
Not Sub
ect to NDA
NR BAND Duplex Mode
Uplink
Frequency (MHz)
Downlink
Frequency (MHz)
Channels
SCS
(kHz)
n28 - 700 APT FDD 703 - 748 758 - 803
Tx: 140600 - 149600
Rx: 151600 - 160600
15
n30 - WCS FDD 2305 - 2315 2350 - 2360
Tx: 461000 - 463000
Rx: 470000 - 472000
15
n38 - 2600 TDD 2570 - 2620 T/Rx: 514000 - 524000
30
n40 - 2300 TDD 2300 - 2400 T/Rx: 460000 - 480000
30
n41 - 2600+ TDD 2496 - 2690 T/Rx: 499200 - 537996
30
n48 - 3600 TDD 3550 - 3700 T/Rx: 636668 - 646666
30
n66 - AWS-3 FDD 1710 - 1780 2110 - 2200
Tx: 342000 - 356000
Rx: 422000 - 440000
15
n71 - 600 FDD 663 - 698 617 - 652
Tx: 132600 - 139600
Rx: 123400 - 130400
15
n75 – DL 1500+ SDL - 1432 – 1517 Rx: 286400 - 303400
30
n77 - 3700 TDD 3300 - 4200 T/Rx: 620000 - 680000
30
n78 - 3500 TDD 3300 - 3800 T/Rx: 620000 - 653332
30
n79 - 4700 TDD 4400 - 5000 T/Rx: 693334 - 733332
30
Table 2: 5G NR Sub-6 Bands supportive
LTE Bands supportive
E-UTRA BAND Duplex Mode
Uplink Frequency
(MHz)
Downlink Frequency
(MHz)
Channels
B1 - 2100 FDD 1920 - 1980 2110 - 2170
Tx: 18000 - 18599
Rx: 0 - 599
B2 - 1900 PCS FDD 1850 - 1910 1930 - 1990
Tx: 18600 - 19199
Rx: 600 - 1199
B3 - 1800+ FDD 1710 - 1785 1805 - 1880
Tx: 19200 - 19949
Rx: 1200 - 1949
B4 - AWS-1
FDD 1710 - 1755 2110 - 2155
Tx: 19950 - 20399
Rx: 1950 - 2399
B5 - 850
FDD 824 - 849 869 - 894
Tx: 20400 - 20649
Rx: 2400 - 2649
B7 - 2600
FDD 2500 - 2570 2620 - 2690
Tx: 20750 - 21449
Rx: 2750 - 3449
B8 - 900 GSM
FDD 880 - 915 925 - 960
Tx: 21450 - 21799
Rx: 3450 - 3799
B12 - 700 a
FDD 699 - 716 729 - 746
Tx : 23010 - 23179
Rx : 5010 - 5179
B13 - 700 c
FDD 777 - 787 746 - 756
Tx : 23180 - 23279
Rx : 5180 - 5279
B14 - 700 PS
FDD 788 - 798 758 - 768
Tx : 23280 - 23379
Rx : 5280 - 5379
B17 - 700 b
FDD 704 - 716 734 - 746
Tx: 23730 - 23849
Rx: 5730 - 5849
B18 - 800 Lower
FDD 815 - 830 860 - 875
Tx: 23850 - 23999
Rx: 5850 - 5999
