FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 17 of 92 2022-10-07
Not Sub
ect to NDA
Band Power class RF Power (dBm)
3G WCDMA
B1, B2, B4, B5, B6, B8, B19
3 (0.2W) 23 (+2dB / -2dB)
Table 7: Conducted Transmit Output Power
2.6.2. Conducted Receiver Sensitivity
The Sensitivity of the receiver follows the measurement conditions and specifications
defined in 3GPP.
Technology 3GPP Compliance
5G NR Sub-6 Throughput >95%
4G LTE Throughput >95%
3G WCDMA BER <0.1% 12.2 Kbps
Table 8: 3GPP compliance for Conducted Receiver Sensitivity
NR Band Typical Conducted Rx Sensitivity (dBm) *
SCS (kHz) BW (MHz) ANT0 ANT1 ANT2 ANT3 Combined
NR FDD n1 15 20 -95 -94 -96 -95 -100
NR FDD n2 15 20 -95 -94 -95 -95 -100
NR FDD n3 15 20 -94 -94 -96 -95 -100
NR FDD n5 15 20 -96 NA -98 NA -99
NR FDD n7 15 20 -93 -94 -94 -95 -99
NR FDD n8 15 20 -96 NA -98 NA -99
NR FDD n20 15 20 -96 NA -98 NA -100
NR FDD n25 15 20 -94 -94 -95 -95 -100
NR FDD n28 15 20 -96 NA -98 NA -100
NR FDD n30 15 10 -96 -96 -98 -98 -102
NR TDD n38 30 20 -95 -94 -94 -94 -99
NR TDD n40 30 80 -88 -88 -88 -89 -93
NR TDD n41 30 100 -88 -86 -87 -87 -92
NR TDD n48 30 40 -91 -91 -93 -92 -97
NR FDD n66 15 20 -94 -94 -95 -97 -99
