6.4.2. Using a GPIO as OUTPUT
GPIO pins, when used as output, can drive 1.8V CMOS digital devices or compatible
hardware. When set as outputs, the pins have a push-pull output, and therefore the pull-
up resistor can be omitted.
Figure 18: GPIO Output Pin Equivalent Circuit
