FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 84 of 92 2022-10-07
Not Sub
ect to NDA
Max Gain for RED (dBi)
NR
Ant Gain to meet CE
MPE limit
Max Gain to consider
EN-DC Active
Max Gain to consider
EN-DC Transmit
with WLAN
Max gain allowed
n38 12.0 9.0 8.6 8.6
n40 12.0 9.0 8.6 8.6
n41 9.0 6.0 5.6 5.6
n77 12.0 9.0 8.6 8.6
n78 90.1 6.0 5.6 5.6
Table 63: Max Antenna Gain for RED in dBi – NR bands
RoHS and REACH Info
11.5.1. RoHS Info
Any requests on information related to RoHS certifications can be addressed to
Chemical.Certifications@telit.com
.
11.5.2. REACH Info
Any requests on information related to REACH certifications can be addressed to
Chemical.Certifications@telit.com.
