FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 14 of 92 2022-10-07
Not Sub
j
ect to NDA
Main Features
The FN990 Family of industrial grade cellular modules features 5G Sub-6, LTE and multi-
RAT module together with an on-chip powerful application processor and a rich set of
interfaces.
Main functions and features are listed below:
Function Features
Physical M.2 Type 3052-S3-B
Cellular technology
FN990A28
5G: FR1(Sub 6G), Rel 16
4G: CAT. 19 (1.6Gbps) on DL, CAT. 18 (211Mbps) on UL, Rel 16
3G: HSPA+ Rel9 up to 42/5.7Mbps in DL/UL
FN990A40
5G: FR1(Sub 6G), Rel 16
4G: CAT. 20 (2Gbps) on DL, CAT. 18 (211Mbps) on UL, Rel 16
3G: HSPA+ Rel9 up to 42/5.7Mbps in DL/UL
4x4 MIMO
5G: n1/n2/n3/n7/n25/n30/n38/n40/n41/n48/n66/n75/n77/n78/n79
4G: B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66
Diversity/2
nd
Rx
4G: all operating bands
3G: all operating bands
GNSS Upper L-band: GPS/Glonass/Beidou/Galileo
USIM port – Dual Voltage
Two SIM support (UIM2 can be assigned as optional eSIM)
Class B and Class C support
Application processor
Application processor to run customer application code
32 bit ARM s-A7 up to 1.8 GHz running the Linux operating system
4Gbit NAND Flash + 4Gbit LPDDR4 2133 MHz MCP is supported
Main Interfaces
PCIe Gen3 x 1-lane
USB 3.1 Gen 2
Peripheral Ports – GPIOs
Antenna connection
4 x MHF-4 type Cellular/GNSS antenna connectors
1 x MHF-4 type Dedicated GNSS antenna connector
From factor M.2 Form factor (30 * 52 * 2.25 mm), accommodating the multiple RF bands
Environment and quality
requirements
The device is designed and qualified by Telit to satisfy environmental and quality
requirements.
Single supply module The module internally generates all its required internal supply voltages.
