Telit Wireless Solutions FN990 Series User Manual

FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 83 of 92 2022-10-07
Not Sub
j
ect to NDA
Max Gain for RED (dBi)
UMTS
Ant Gain to meet CE
MPE limit
Max Gain to consider
same Frequency
with LTE
Max Gain to consider
EN-DC Transmit
with WLAN
Max gain allowed
B1 11.1 8.8 8.5 8.5
B3 10.6 8.3 8.0 8.0
B8 7.8 5.4 5.0 5.0
Table 61: Max Antenna Gain for RED in dBi – WCDMA bands
Max Gain for RED (dBi)
LTE
Ant Gain to meet CE
MPE limit
Max Gain to consider
EN-DC Active
Max Gain to consider
EN-DC Transmit
with WLAN
Max gain allowed
B1 11.8 8.8 8.5 8.5
B3 11.3 8.3 8.0 8.0
B7 12.0 9.0 8.6 8.6
B8 8.5 5.4 5.0 5.0
B20 8.2 5.1 4.8 4.8
B28 7.5 4.4 4.0 4.0
B38 12.0 9.0 8.6 8.6
B40 12.0 9.0 8.6 8.6
B42 12.0 9.0 8.6 8.6
B43 15.0 12.0 11.0 11.0
Table 62: Max Antenna Gain for RED in dBi – LTE bands
Max Gain for RED (dBi)
NR
Ant Gain to meet CE
MPE limit
Max Gain to consider
EN-DC Active
Max Gain to consider
EN-DC Transmit
with WLAN
Max gain allowed
n1 11.84 8.8 8.5 8.5
n3 11.33 8.3 8 8.0
n7 12.01 9 8.6 8.6
n8 8.5 5.4 5.0 5.0
n20 8.2 5.1 4.8 4.8
n28 7.5 4.4 4.0 4.0
