FN990
Family Hardware Design Guide
1VV0301752 Rev. 3 Page 58 of 92 2022-10-07
Not Sub
ect to NDA
Antenna port Technology Tx Rx GNSS
ANT 1
WCDMA - -
GPS L1,
Galileo E1,
Beidou B1,
Glonass G1
LTE -
B1, B2, B3, B4, B7, B25, B30,
B32(DL), B34, B38, B39, B40,
B41, B42, B43, B48, B66
5G NR FR1 n48, n77, n78, n79
n1, n2, n3, n7, n25, n30, n38,
n40, n41, n48, n66, n75(DL),
n77, n78, n79
ANT 2
WCDMA - B1, B2, B4, B5, B6, B8, B19
-
LTE -
B1, B2, B3, B4, B5, B7, B8, B12,
B13, B14, B17, B18, B19, B20,
B25, B26, B28, B29(DL), B30,
B32(DL), B34, B38, B39, B40,
B41, B42, B43, B46(DL), B48,
B66, B71
5G NR FR1 n38, n41
n1, n2, n3, n7, n25, n30, n38,
n40, n41, n48, n66, n75, n77,
n78, n79
ANT 3
WCDMA - -
-
LTE B42, B43, B48
B1, B2, B3, B4, B7, B25, B30,
B32(DL), B34, B38, B39, B40,
B41, B42, B43, B48, B66
5G NR FR1 n48, n77, n78, n79
n1, n2, n3, n7, n25, n30, n38,
n40, n41, n48, n66, n75(DL),
n77, n78, n79
ANT 4 GNSS - -
GPS L1,
Galileo E1,
Beidou B1,
Glonass G1
Table 38: Antenna Configuration
Please refer to the tables below for antenna port on each supported band:
NR Band
ANT0 ANT1 ANT2 ANT3
NR FDD n1 PRx/Tx0 MIMO1 DRx MIMO2
NR FDD n2 PRx/Tx0 MIMO1 DRx MIMO2
NR FDD n3 PRx/Tx0 MIMO1 DRx MIMO2
NR FDD n5 PRx/Tx0 NA DRx NA
NR FDD n7 PRx/Tx0 MIMO1 DRx MIMO2
NR FDD n8 PRx/Tx0 NA DRx NA
NR FDD n20 PRx/Tx0 NA DRx NA
NR FDD n25 PRx/Tx0 MIMO1 DRx MIMO2
