Tenda 11AC User Manual

78
---End
Wait for the automatic reboot of the AP.
Configure the switch
Create IEEE 802.1Q VLANs described in the following table on the switch.
Port Connected To
Accessible VLAN ID
Port Type
PVID
AP
1,2,3,4
Trunk
1
LAN server
3,4
Trunk
1
Router
2,4
Trunk
1
Retain the default settings of other ports. For details, refer to the user guide for the switch.
---End
Verification
Wireless clients connected to the internet wireless network can only access the internet, wireless clients
connected to the oa wireless network can only access the LAN. Wireless clients connected to the VIP wireless
network can access both the internet and LAN.
*
*
*
*
