Tenda AP4 User Manual

109
----End
Parameters description
Name
Description
Mode
It specifies the mode of MAC filter rule.

Disable: Disable the MAC Filter function.

Allow: Allow the devices with the MAC addresses in the list to access the internet
via this device, and disallow the other devices to access the internet via this device.

Disallow: Disallow the devices with the MAC addresses in the list to access the
internet via this device, and allow the other devices to access the internet via this
device.
Remark
It specifies the additional information of the rule.
MAC Address
It specifies the MAC address of the device to which the rule applies.
Time
It specifies the period at which and dates on which the rule takes effect.
Date
Status
It specifies the status of the rule. You can tick or untick the Enable option to enable or
disable the rule.
Action
Click to delete the rule.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
