Tenda AP4 User Manual

113
----End
Parameters description
Name
Description
DDNS
It specifies whether to enable the DDNS function.
Service Provider
It specifies Dynamic Domain Name Service provider. The device supports Dyndns,
No-ip.com, and 3322.org.
User Name
It specifies the username and password used to log in to a DDNS service provider.
Password
Domain Name
It specifies the domain name information obtained from the dynamic DNS server.
Example of configuring DDNS
Networking requirement
The device is used to bridge to the ISP hotspot for internet access in a house in the countryside, and
the device is set to WISP mode. The WAN IP address of the device is dynamic.
The administrator on business can visit the resources on web server in LAN.
You are recommended to use the DDNS and port forwarding functions to meet the requirement.
Assume that:
The information of the web server in LAN is shown as follows:
− Static IP Address: 192.168.0.100
− Service Port of the Web Server: 80
The registered domain name information is shown as follows:
− Service Provider: Dyndns
− User Name: tenda

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
