Tenda AP4 User Manual

129
8.2.4 Backup/restore
The backup function enables you to export the configuration of the device to a local computer, and
import the configuration file you export before.
You are recommended to back up the new configuration, so that you can restore it after upgrading
or resetting the device.
If you need to apply same or similar configurations to many devices, you can configure one of the
devices, back up the configuration of the device, and use the backup to restore the configuration on the
other devices. This improves configuration efficiency.
Backup
Configuration procedure
Step 1 Log in to the web UI of the device, and choose Tools > Maintenance.
Step 2 Click Backup/Restore.
Step 3 Then click Backup on the pop-up window.
----End
A file named APCfm.cfg is downloaded to your local computer.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
