Tenda AP4 User Manual

60
Name
Description
connects.
If the IP Address Type is set to DHCP (Dynamic IP Address), you need to check the
device’s IP address on the clients list of the DHCP server to which it connects, and use
this IP address to log in.
IP Address
It specifies the LAN IP address of the device. The default is 192.168.0.254.
Subnet Mask
It specifies the subnet mask of the device. The default is 255.255.255.0.
Default Gateway
It specifies the default gateway of the device.
You can set it to the IP address of the egress router to enable the device to access the
internet.
Primary DNS Server
It specifies the primary DNS server IP address of the device.
If the egress router has the DNS agent function, you can manually set this parameter
to the LAN IP address of the egress router.
Secondary DNS Server
Optional. It specifies the secondary DNS server IP address of the device.
Device Name
It specifies the name of the device. The default name indicates the product model
and version.
A unique device name helps you manage multiple devices that are of the same model
on LAN easily. You are allowed to modify only when the device works in AP, Client,
Universal Repeater, or Client + AP mode.
In WISP and Router modes, the page displays:

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
