Parameters description
Name
Description
MAC Address
It specifies the MAC address of LAN port.
IP Address Type
It specifies the type of obtaining an IP address. The default is Static IP Address.

Static IP Address: Specify the IP address and subnet mask manually.

DHCP (Dynamic IP Address): The device obtains an IP address and subnet mask
from the upstream DHCP server in the network.
If the IP Address Type is set to DHCP (Dynamic IP Address), you need to check the
device’s IP address on the clients list of the DHCP server of the upstream device, and
use this IP address to log in.
IP Address
It specifies the LAN IP address of the device. The default is 192.168.0.254.
Subnet Mask
It specifies the subnet mask corresponding to the LAN IP address of the device. The
default is 255.255.255.0.
5.1.2 Setting an LAN IP address manually
This method applies to a small LAN network with a few APs. With this method, you need manually
set the IP address, subnet mask, gateway IP address, and DNS server IP addresses of the device.
Therefore, this mode is recommended if you need to deploy only a few devices.
Configuration procedure:
Step 1 Choose Network > LAN Setup to enter the configuration page.
Step 2 Select Static IP Address from the IP Address Type drop-down list.
Step 3 Set IP Address, Subnet Mask, Default Gateway, and Primary DNS Server.
Step 4 Customize a device name as required.
Step 5 Click Save.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
