PW201A Wireless N Powerline AP User Guide
71
Powerline devices, clients connected wirelessly to the PW201A are able to
access Internet. B. Simply connect the PW201A to an Internet-enabled
broadband router using an Ethernet cable. And clients connected wirelessly
to the PW201A will be able to access Internet.
4. Q: Do I need to install a utility to use the device?
A: No. The device is a plug-&-play Powerline device. Two Powerline
devices connected to the same electricity meter are able to interconnect
automatically, no configuration required. Yet, there is still an included Web
based utility for configuring advanced features.
5. Q: I want to access Internet and manage the PLC AP concurrently
from my PC. What should I do?
A: First, set your PC's IP address to "192.168.0.x" where x represents
any integer between 2 and 253. Second, Launch a web browser and access
the Device's web utility. Third, enter the LAN configuration screen and
change the Device's LAN IP to an IP address that is on the same IP net
segment as the LAN IP of an Internet-enabled broadband router (note it
down for future use). Fourth, set your PC to "Obtain an IP address
automatically". Now you can access Internet while managing the Device.

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
