Terramite T5D - Cylinder Components

WWW.TERRAMITE.COM
Charleston, WV/USA
USA 1.800.428.3772
Intl. 1 .304.776.4231
Read Operators Manual For SafetyPARTS MANUAL
Copyright © 2007 Terramite Corporation
Cylinder Components
Cylinder Rod Bearing Block Piston Seal Kit
Rod Part Part Part Part Part
Diameter Number Number Number Number Number
Power Steering T5D/T7 1" 25811 25803 22103 21111 21151
Power Steering T7 1" 81212 25803 22103 21111 21151
Swing T5D/T7 1" 82070 25201 22103 21111 21151
Swing T7 180 Degree Swing 1
1
/4" 81169 81228 81230 81227 81233
Arm T5D/T7 1
1
/8" 12026 81042 22203 21111 21125
Front Curl T5D/T7 1
1
/8" 82073 22203 21111 21125
Rear Curl T5D/T7 1
1
/4" 81158 81048 82104 21111 82051
Outrigger T5D/T7 1
1
/8" 81139 21601 22203 21111 21125
Boom T5D Straight Boom 1
1
/4" 21200 21201 82058 23110 21525
Crowd T5D Straight Boom 1
1
/4" 21000 21201 82058 23110 21525
Boom/Crowd T7 Curved Boom 1
1
/4" 81152 82089 82104 21111 21525
Boom T7 180 DegreeSwing 1
1
/2" 81190 81205 81192 81237 81196
Crowd T7 180 Degree Swing 1
1
/2" 81222 81205 81192 81237 81196
1 2 3 4 5 6
82066 Left
82074 Right
4.39
