Terramite T5D - Decal Location - Rear Valve

WWW.TERRAMITE.COM
Charleston, WV/USA
USA 1.800.428.3772
Intl. 1 .304.776.4231
Read Operators Manual For SafetyPARTS MANUAL
Copyright © 2007 Terramite Corporation
ITEM PART NUMBER DESCRIPTION QTY.
1 14284 Decal, Operator Danger T7/T9 1
2 14207 Decal, Vertical, Read Owners Manual, T5C/T5D/T6/T7/T9 1
3 14112 Decal, Boom Latch Operator, T7/T9 1
Decal Location - Rear Valve
1
2
3
1
2
3
READ
OWNER’S
MANUAL
BEFORE
OPERATING
BOOM LATCH
TO ENGAGE
BOOM LATCH
1. Raise boom to
full UP position
2. Using control
cable, lower boom
latch onto pins
3. Lower boom
to lock position
TO DISENGAGE
BOOM LATCH
1. Raise boom to
full UP position
2. Pull handle and
turn clockwise
to lock boom latch
in disengaged
position
3. Operate backhoe
TMC P/N 14112
