Terramite T5D - T7 Pin Chart (180 Degree Boom)

WWW.TERRAMITE.COM
Charleston, WV/USA
USA 1.800.428.3772
Intl. 1 .304.776.4231
Read Operators Manual For Safety PARTS MANUAL
Copyright © 2007 Terramite Corporation
T7 CURVED BOOM PINS
ITEM P/N DESCRIPTION SIZE
1 13200 FRONT BUCKET/ARMS 1” x 4 3/4”
2 17176 ARM LINK/ARM CYLINDER 1” x 5 1/2”
3 17178 ARM LINK/ARM - TAPPED 1” x 5 1/2”
4 17179 ARM BUCKET/FRONT CURL 1” x 5 1/2”
5 12600 ARM CYLINDER/ARMS 1” x 5 1/4”
6 12300 ARM/FRAME 1” x 6 7/8”
7 12301 ARM CYLINDER/FRAME 1” x 7 7/8”
8 17198 ARM/CYLINDER/FRAME 1” x 8 1/2”
9 10700 CROWD & REAR CURL CYLINDER/DIPPER 1” x 6 7/8”
10 17031 LINKAGE CURL/CYLINDER 1” x 7 3/8”
11 10206 R.C. CYLINDER/BUCKET Q.D. & BOOM LATCH 1” x 6 1/2”
12 19072 REAR BUCKET PULL 1” x 8 1/2”
13 17190 Q.A. BUCKET 1 1/4” x 8 1/4”
14 10812 DIP/LINKAGE 1 1/4” x 7 5/8”
15 10701 BOOM/DIPPER 1 1/4” x 7 1/4”
16 17208 BOOM CYL./SWING 1 1/4” x 8 1/4”
17 10406 BOOM/SWING 1 1/2” x 7 1/4”
18 11100 CRD-BM CYL/BM,O.R/FRAME 1" x 6 1/4"
19 11502 OUTRIGGERS 1” x 4 1/8”
20 17156 OUTRIGGER PAD - PULL PIN 1” x 5 1/4”
21 17244 SWING CYL/FRAME 1 1/4” x 5 1/2”
22 17253 SWING CYL/SWING 1 1/2” x 4 3/4”
T7 Pin Chart (180 Degree Boom)
4.6
