Read Operators Manual For Safety PARTS MANUAL
Copyright © 2007 Terramite Corporation
ITEM PART NUMBER DESCRIPTION QTY.
1 13947 Link, “L”, Front Valve, All Tractors 1
2 13965 Linkage, Ball-Socket, Wobblestick, All Tractors 1
3 13413 Pin, Cotter,
3
/32” x
5
/8”, Linkage, Valve, All Tractors 1
4 25500 Nut,
5
/16” - 24 NF Jam 1
5 13944 Block, Pivot, Wobblestick, Front, T5C/T5D/T6/T7/T9 1
6 13411 Link, “U”, Valve, All Tractors 1
7 13995 Bolt, Wobblestick Hinge, Front, All Tractors 1
View of Front Valve Linkage Assembly
1
2 3 4 5 6 7
2.22
