Read Operators Manual For SafetyPARTS MANUAL
Copyright © 2007 Terramite Corporation
View from Operator Position of Rear Valve
1 2 3 4 2 5
7869 9 6
ITEM PART NUMBER DESCRIPTION QTY.
1 25500 Nut,
5
/16” - 24 NF Jam 5
2 13444 Block, Pivot, Universal Rear, T5C/T5D/T6/T7/T9 1
3 21429 Fitting, Grease,
1
/4” 90°D 7
4 14052 Plate, Wobblestick & Operator Hazard, T5C/T5D/T6/T7/T9 1
5 13965 Linkage, Ball-Socket, Wobblestick, All Tractors 3
6 13418 Pin, Pivot, Valve Hose Link, T5C/T5D/T6/T7 10
7 13443 Link Bar, Wobblestick Connecting, T5C/T5D/T6/T7/T9 3
8 13411 Link, “U”, Valve All Tractors 3
9 13410 Bracket, Aluminum, Rear Valve Handle, T6/T9 2
Prior to 1-1-01
Non 180 Only
2.39
To Next Page
