Read Operators Manual For Safety PARTS MANUAL
Copyright © 2007 Terramite Corporation
ITEM PART NUMBER HYDRASTATIC TRANSMISSION DESCRIPTION QTY.
1 60401 Retaining Ring 1
2 60402 Shaft Seal 1
3 60403 Washer 1
4 60404 Retaining Ring 2
5 60405 Bearing Race 2
6 60406 Bearing, Thrust 1
7 60471 Key 1
8 60407 Drive Shaft 1
9 60409 Housing Assembly 1
10 60410 Bearing 2
11 60411 Inner Race 2
12 60412 O-Ring,
3
/32" x
15
/16", Outer Pintle 2
13 60465 Sleeve Cover 1
13A 60415 Trunnion Cover 1
13B 60561 Washer 1
14 60414 Retaining Ring 2
14A 60562 Seal, Pintle 1
15 60418 Seal Cover 1
17 60564 Screws, Trunnion Cover 2
18 60516 O-Ring, Outer Pintle 1
19 60517 Camplate, For Eaton Trans. 1
19 60417 Camplate, For Cessna Trans. 1
29 60422 Rotating Kit Assembly 1
31 60429 Housing, Gasket 1
33 60533 Backplate Assy., Eaton, with Power Steering 1
33A 60535 Backplate Assy., w/valve plate, Eaton 1
33B 60432 Backplate Assy., Cessna, without Power Steering 1
35 60436 Plug Assembly 2
36 60435 O-Ring 3
3
/32" x
7
/8" ID, Back Plate 1
37 60434 Spring, Transmission, Relief Valve 2
38 60467 Relief Valve Assembly 2
39 60433 Plug Assembly 1
40 60440 Retaining Ring 1
41 60441 Separator Plug 1
42 60442 O-Ring, 3
3
/32" x
7
/8" 1
43 60454 Spreader 1
44 60437 O-Ring,
1
/16" x
3
/8" 1
45 60443 Coupler 1
50 64050 Gerotor and Coupler 1
51 60449 O-Ring, Molded 1
60453 Adapter Assembly without Power Steering
52 60553 Adapter Assembly with Power Steering 1
64058 Adapter Assembly with Power Steering - Diesel
53 60450 Check Valve Assembly 2
54 60452 Back Up Washer 2
55 60455 O-Ring,
1
/16" x
7
/16" 2
56 60456 Steel Ball 2
57 60457 Pin 2
58 60461 Poppet Filter Relief 1
59 60463 Spring 1
60 60560 Spring Retainer 1
61 60469 Plug Assembly 1
62 60466 O-Ring, 3
3
/32" x
41
/64"1
64 60464 O-Ring,
1
/16" x 3
1
/4" 1
65 60465 Cover Plate 1
66 60459 Cap Screw 2
67 60534 Plate, Valve 1
*S 64100 Seal Repair Kit, Cessna 1
*S 64101 Seal Repair Kit Eaton 1
*S 60043 Rotating Rebuild Kit, Cessna 1
*S 60564 Screws, Trunnion Cover 2
68 60464 O-Ring in Back 1
