AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
I2C
I2C/I2C0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
I2C0_SCL I2C0 Clock I/OD B19 C16
I2C0_SDA I2C0 Data I/OD C18 C17
I2C/I2C1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
I2C1_SCL I2C1 Clock I/OD A17, C19, F18, A16, D15, E17,
K19 J15
I2C1_SDA I2C1 Data I/OD B17, D18, F19, B16, D16, E18,
J18 H17
I2C/I2C2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
I2C2_SCL I2C2 Clock I/OD B18, D19, F17 B17, D17, E16
I2C2_SDA I2C2 Data I/OD A18, E17, E19 A17, D18, E15
74 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
