AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
McASP
McASP/MCASP0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mcasp0_aclkr McASP0 Receive Bit Clock I/O L19, V18, V6 B12, J17, U18,
V2
mcasp0_aclkx McASP0 Transmit Bit Clock I/O N19, V4 A13, K18, U1,
V16
mcasp0_ahclkr McASP0 Receive Master Clock I/O V5 C12, U4
mcasp0_ahclkx McASP0 Transmit Master Clock I/O N18, V7 A14, K15, T5
mcasp0_axr0 McASP0 Serial Data (IN/OUT) I/O N17, U5 D12, L17, T16,
U3
mcasp0_axr1 McASP0 Serial Data (IN/OUT) I/O N16, W6 D13, L16, V17,
V4
mcasp0_axr2 McASP0 Serial Data (IN/OUT) I/O J19, V5, V6 B12, C12, H16,
U4, V2
mcasp0_axr3 McASP0 Serial Data (IN/OUT) I/O P18, U6, V7 A14, C13, M16,
T5, V3
mcasp0_fsr McASP0 Receive Frame Sync I/O M17, U6, V16 C13, J18, V12,
V3
mcasp0_fsx McASP0 Transmit Frame Sync I/O M19, W4 B13, L18, U16,
U2
McASP/MCASP1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mcasp1_aclkr McASP1 Receive Bit Clock I/O L18, P18 K17, M16
mcasp1_aclkx McASP1 Transmit Bit Clock I/O J18, L19 B12, H17, J17
mcasp1_ahclkr McASP1 Receive Master Clock I/O P18 M16
mcasp1_ahclkx McASP1 Transmit Master Clock I/O K18, P18 H18, M16
mcasp1_axr0 McASP1 Serial Data (IN/OUT) I/O K17, N18 D13, J16, K15
mcasp1_axr1 McASP1 Serial Data (IN/OUT) I/O M18 A14, K16
mcasp1_axr2 McASP1 Serial Data (IN/OUT) I/O J19, L18 H16, K17
mcasp1_axr3 McASP1 Serial Data (IN/OUT) I/O K18, P19 H18, L15
mcasp1_fsr McASP1 Receive Frame Sync I/O M18, P19 K16, L15
mcasp1_fsx McASP1 Transmit Frame Sync I/O K19, M17 C13, J15, J18
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 75
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
