Page #76 background imageLoading...
Page #76 background image
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H OCTOBER 2011REVISED MAY 2015
www.ti.com
SPI
SPI/SPI0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
spi0_cs0 SPI Chip Select I/O A17 A16
spi0_cs1 SPI Chip Select I/O B16 C15
spi0_d0 SPI Data I/O B18 B17
spi0_d1 SPI Data I/O B17 B16
spi0_sclk SPI Clock I/O A18 A17
SPI/SPI1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
spi1_cs0 SPI Chip Select I/O E17, E19, F18, C12, D18, E15,
K18 E17, H18
spi1_cs1 SPI Chip Select I/O C15, D19, E18, A15, C18, D17,
F17 E16
spi1_d0 SPI Data I/O F19, J18 B13, E18, H17
spi1_d1 SPI Data I/O F18, K19 D12, E17, J15
spi1_sclk SPI Clock I/O E18, J19 A13, C18, H16
76 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
