Abbreviations
Abbreviations used in this data sheet are described below.
2-FSK
Binary Frequency Shift Keying
MSB
Most Significant Bit
4-FSK
Quaternary Frequency Shift Keying
MSK
Minimum Shift Keying
ACP
Adjacent Channel Power
N/A
Not Applicable
ADC
Analog to Digital Converter
NRZ
Non Return to Zero (Coding)
AFC
Automatic Frequency Compensation
OOK
On-Off Keying
AGC
Automatic Gain Control
PA
Power Amplifier
AMR
Automatic Meter Reading
PCB
Printed Circuit Board
ASK
Amplitude Shift Keying
PD
Power Down
BER
Bit Error Rate
PER
Packet Error Rate
BT
Bandwidth-Time product
PLL
Phase Locked Loop
CCA
Clear Channel Assessment
POR
Power-On Reset
CFR
Code of Federal Regulations
PQI
Preamble Quality Indicator
CRC
Cyclic Redundancy Check
PQT
Preamble Quality Threshold
CS
Carrier Sense
PTAT
Proportional To Absolute Temperature
CW
Continuous Wave (Unmodulated Carrier)
QLP
Quad Leadless Package
DC
Direct Current
QPSK
Quadrature Phase Shift Keying
DVGA
Digital Variable Gain Amplifier
RC
Resistor-Capacitor
ESR
Equivalent Series Resistance
RF
Radio Frequency
FCC
Federal Communications Commission
RSSI
Received Signal Strength Indicator
FEC
Forward Error Correction
RX
Receive, Receive Mode
FIFO
First-In-First-Out
SAW
Surface Aqustic Wave
FHSS
Frequency Hopping Spread Spectrum
SMD
Surface Mount Device
FS
Frequency Synthesizer
SNR
Signal to Noise Ratio
GFSK
Gaussian shaped Frequency Shift Keying
SPI
Serial Peripheral Interface
IF
Intermediate Frequency
SRD
Short Range Devices
I/Q
In-Phase/Quadrature
TBD
To Be Defined
ISM
Industrial, Scientific, Medical
T/R
Transmit/Receive
LC
Inductor-Capacitor
TX
Transmit, Transmit Mode
LNA
Low Noise Amplifier
UHF
Ultra High frequency
LO
Local Oscillator
VCO
Voltage Controlled Oscillator
LSB
Least Significant Bit
WOR
Wake on Radio, Low power polling
LQI
Link Quality Indicator
XOSC
Crystal Oscillator
MCU
Microcontroller Unit
XTAL
Crystal
