Texas Instruments CC1101 User Manual

CC1101
SWRS061H Page 8 of 98
1 Absolute Maximum Ratings
Under no circumstances must the absolute maximum ratings given in Table 1 be violated. Stress
exceeding one or more of the limiting values may cause permanent damage to the device.
Table 1: Absolute Maximum Ratings
Caution! ESD sensitive device.
Precaution should be used when handling
the device in order to prevent permanent
damage.
2 Operating Conditions
The operating conditions for CC1101 are listed Table 2 in below.
Table 2: Operating Conditions
3 General Characteristics
Table 3: General Characteristics
Parameter
Min
Max
Units
Condition
Supply voltage
–0.3
3.9
V
All supply pins must have the same voltage
Voltage on any digital pin
–0.3
VDD + 0.3,
max 3.9
V
Voltage on the pins RF_P, RF_N,
DCOUPL, RBIAS
–0.3
2.0
V
Voltage ramp-up rate
120
kV/µs
Input RF level
+10
dBm
Storage temperature range
–50
150
C
Solder reflow temperature
260
C
According to IPC/JEDEC J-STD-020
ESD
750
V
According to JEDEC STD 22, method A114,
Human Body Model (HBM)
ESD
400
V
According to JEDEC STD 22, C101C,
Charged Device Model (CDM)
Parameter
Min
Max
Unit
Condition
Operating temperature
-40
85
C
Operating supply voltage
1.8
3.6
V
All supply pins must have the same voltage
Parameter
Min
Typ
Max
Unit
Condition/Note
Frequency
range
300
348
MHz
387
464
MHz
If using a 27 MHz crystal, the lower frequency limit for
this band is 392 MHz
779
928
MHz
Data rate
0.6
0.6
0.6
26
500
250
300
500
kBaud
kBaud
kBaud
kBaud
2-FSK
GFSK, OOK, and ASK
4-FSK (the data rate in kbps will be twice the baud rate)
(Shaped) MSK (also known as differential offset QPSK).
Optional Manchester encoding (the data rate in kbps will
be half the baud rate)
