Texas Instruments MSPM0G350 Series User Manual

Table 6-1. Pin Attributes (continued)
PINCMx
PIN
NAME
SIGNAL NAMES PIN NUMBER
IO
STRUCTU
RE
ANALOG DIGITAL [PIN FUNCTION]
(1)
64 LQFP
48 LQFP, VQFN
32 VQFN
28 VSSOP
37
PA15 A1_0 / DAC_OUT /
OPA0_IN2+ /
OPA1_IN2+/
COMP0_IN3+ /
COMP1_IN3+
UART0_RTS [2] / SPI1_CS2 [3] / I2C1_SCL [4] / TIMA1_C0
[5] / TIMG8_IDX [6] / TIMA1_C0N [7] / TIMA0_C2 [8]
8 30 19 18 Standard
38
PA16
A1_1 / OPA1_OUT
COMP2_OUT [2] / SPI1_POCI [3] / I2C1_SDA [4] /
TIMA1_C1 [5] / TIMA1_C1N [6] / TIMA0_C2N [7] / FCC_IN
[8]
9 31 20 19 Standard
39
PA17
A1_2 / OPA1_IN1- /
COMP0_IN1-
UART1_TX [2] / SPI1_SCK [3] / I2C1_SCL [4] / TIMA0_C3
[5] / TIMG7_C0 [6] / TIMA1_C0 [7]
10 32 21 20
Standard
with
wake
(2)
40
PA18 A1_3 / OPA1_IN1+ /
COMP0_IN1+ /
GPAMP_IN-
UART1_RX [2] / SPI1_PICO [3] / I2C1_SDA [4] /
TIMA0_C3N [5] / TIMG7_C1 [6] / TIMA1_C1 [7]
11 33 22 21
Standard
with
wake
(2)
41
PA19
SWDIO [2] 12 34 23 22
High-
Speed
42 PA20 SWCLK [2] 13 35 24 23 Standard
43
PB17
A1_4 / COMP1_IN2-
UART2_TX [2] / SPI0_PICO [3] / SPI1_CS1 [4] / TIMA1_C0
[5] / TIMA0_C2 [6]
14 36 – – Standard
44
PB18
A1_5 / COMP1_IN2+
UART2_RX [2] / SPI0_SCK [3] / SPI1_CS2 [4] / TIMA1_C1
[5] / TIMA0_C2N [6]
15 37 – – Standard
45
PB19 A1_6 / COMP2_IN1+ /
OPA1_IN0+
COMP2_OUT [2] / SPI0_POCI [3] / TIMG8_C1 [4] /
UART0_CTS [5] / TIMG7_C1 [6]
16 38 – – Standard
46
PA21 A1_7 / COMP2_IN1- /
VREF-
UART2_TX [2] / TIMG8_C0 [3] / UART1_CTS [4] /
TIMA0_C0 [5] / TIMG6_C0 [6]
17 39 25 24 Standard
47
PA22
A0_7 / GPAMP_OUT /
OPA0_OUT
UART2_RX [2] / TIMG8_C1 [3] / UART1_RTS [4] /
TIMA0_C1 [5] / CLK_OUT [6] / TIMA0_C0N [7] / TIMG6_C1
[8]
18 40 26 25 Standard
48
PB20
A0_6 / OPA1_IN0-
SPI0_CS2 [2] / SPI1_CS0 [3] / TIMA0_C2 [4] / TIMG12_C0
[5] / TIMA_FAL1 [6] / TIMA0_C1 [7] / TIMA1_C1N [8]
19 41 – – Standard
49 PB21 COMP2_IN0+ SPI1_POCI [2] / TIMG8_C0 [3] 20 – – – Standard
50 PB22 COMP2_IN0- SPI1_PICO [2] / TIMG8_C1 [3] 21 – – – Standard
51 PB23 SPI1_SCK [2] / COMP0_OUT [3] / TIMA_FAL0 [4] 22 – – – Standard
52
PB24
A0_5 / COMP1_IN1+
SPI0_CS3 [2] / SPI0_CS1 [3] / TIMA0_C3 [4] / TIMG12_C1
[5] / TIMA0_C1N [6] / TIMA1_C0N [7]
23 42 – – Standard
53
PA23
COMP1_IN1- / VREF+
UART2_TX [2] / SPI0_CS3 [3] / TIMA0_C3 [4] / TIMG0_C0
[5] / UART3_CTS [6] / TIMG7_C0 [7]/ TIMG8_C0 [8]
24 43 27 26 Standard
54
PA24
A0_3 / OPA0_IN1-
UART2_RX [2] / SPI0_CS2 [3] / TIMA0_C3N [4] /
TIMG0_C1 [5] / UART3_RTS [6] / TIMG7_C1 [7] /
TIMA1_C1 [8]
25 44 28 27 Standard
55
PA25
A0_2 / OPA0_IN1+
UART3_RX [2] / SPI1_CS3 [3] / TIMG12_C1 [4] /
TIMA0_C3 [5] / TIMA0_C1N [6]
26 45 29 28 Standard
56 PB25 A0_4 UART0_CTS [2] / SPI0_CS0 [3] / TIMA_FAL2 [4] 27 – – – Standard
57
PB26
COMP1_IN0+
UART0_RTS [2] / SPI0_CS1 [3] / TIMA0_C3 [4] /
TIMG6_C0 [5] / TIMA1_C0 [6]
28 – – – Standard
58
PB27
COMP1_IN0-
COMP2_OUT [2] / SPI1_CS1 [3] / TIMA0_C3N [4] /
TIMG6_C1 [5] / TIMA1_C1 [6]
29 – – – Standard
