Table 8-20. DEVICEID
DEVICEID address is 0x41C4.0004, PARTNUM is bit 12 to 27, MANUFACTURER is bit 1 to 11.
Device PARTNUM MANUFACTURER
MSPM0G3505 0xBB88 0x17
MSPM0G3506 0xBB88 0x17
MSPM0G3507 0xBB88 0x17
Table 8-21. USERID
USERID address is 0x41C4.0008, PART is bit 0 to 15, VARIANT is bit 16 to 23
Device PART VARIANT Device PART VARIANT
MSPM0G3507SPMR 0xAE2D 0xC7 MSPM0G3506SRHBR 0x151F 0xB5
MSPM0G3507SRGZR 0xAE2D 0xF7 MSPM0G3506SDGS28R 0x151F 0x8
MSPM0G3507SPTR 0xAE2D 0x3F MSPM0G3505SPMR 0xC504 0x1D
MSPM0G3507SRHBR 0xAE2D 0x4C MSPM0G3505SRGZR 0xC504 0xC7
MSPM0G3507SDGS28R 0xAE2D 0xCA MSPM0G3505SPTR 0xC504 0x93
MSPM0G3506SPMR 0x151F 0xD4 MSPM0G3505SRHBR 0xC504 0xE7
MSPM0G3506SRGZR 0x151F 0xFE MSPM0G3505SDGS28R 0xC504 0x8E
MSPM0G3506SPTR 0x151F 0x39 MSPM0G3505TDGS28R 0xC504 0xDF
8.35 Identification
Revision and Device Identification
The hardware revision and device identification values are stored in the memory-mapped FACTORY region,
refer to Device Factory Constants section, which provides read-only data describing the capabilities of a device
as well as any factory-provided trim information for use by application software. Refer to Factory Constants
chapter of the MSPM0 G-Series 80-MHz Microcontrollers Technical Reference Manual for more information.
The device revision and identification information are also included as part of the top-side marking on the device
package. The device-specific errata sheet describes these markings (see Section 10.4)
www.ti.com
MSPM0G3507, MSPM0G3506, MSPM0G3505
SLASEX6A – FEBRUARY 2023 – REVISED JUNE 2023
Copyright © 2023 Texas Instruments Incorporated
Submit Document Feedback
73
Product Folder Links: MSPM0G3507 MSPM0G3506 MSPM0G3505
