7.5 Supply Current Characteristics
7.5.1 RUN/SLEEP Modes
VDD=3.3V. All inputs tied to 0V or VDD. Outputs do not source or sink any current. All peripherals are disabled.
PARAMETER MCLK
-40°C 25°C 85°C 105°C 125°C
UNIT
TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX
RUN Mode
IDD
RUN
MCLK=SYSPLL,
SYSPLLREF=SYSOSC, CoreMark,
execute from flash
80MHz 8 8 8 8 8
mA
48MHz 5 5 5 5 6
MCLK=SYSOSC, CoreMark,
execute from flash
32MHz 3 3 4 4 4
4MHz 0.7 0.7 0.9 1 1
MCLK=SYSPLL,
SYSPLLREF=SYSOSC, CoreMark,
execute from SRAM
80MHz 6 6 6 6 7
48MHz 4 4 4 4 5
MCLK=SYSOSC, CoreMark,
execute from SRAM
32MHz 3 3 3 3 3
4MHz 0.6 0.6 0.8 0.9 1
IDD
RUN
,
per MHz
MCLK=SYSPLL,
SYSPLLREF=SYSOSC, CoreMark,
execute from flash
80MHz 95 96 98 100 105
uA/MHz
MCLK=SYSPLL,
SYSPLLREF=SYSOSC, While(1),
execute from flash
80MHz 52 53 55 57 62
SLEEP Mode
IDD
SLEEP
MCLK=SYSPLL,
SYSPLLREF=SYSOSC, CPU is
halted
80MHz 2711 2759 2919 3079 3458
uA
48MHz 1876 1905 2063 2225 2595
MCLK=SYSOSC, CPU is halted
32MHz 1264 1294 1444 1603 1976
4MHz 434 458 607 766 1139
7.5.2 STOP/STANDBY Modes
VDD=3.3V. All inputs tied to 0V or VDD. Outputs do not source or sink any current. All peripherals not noted are disabled.
PARAMETER ULPCLK
-40°C 25°C 85°C 105°C 125°C
UNIT
TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX
STOP Mode
IDD
STOP0
SYSOSC=32MHz,
USE4MHZSTOP=0,
DISABLESTOP=0
4MHz
337 341 345 349 359
uA
IDD
STOP1
SYSOSC=4MHz,
USE4MHZSTOP=1,
DISABLESTOP=0
176 180 185 189 199
IDD
STOP2
SYSOSC off, DISABLESTOP=1,
ULPCLK=LFCLK
32kHz 45 47 50 54 64
STANDBY Mode
IDD
STBY0
LFCLK=LFXT, STOPCLKSTBY=0,
RTC enabled
32kHz
1.9 2 4 6.91 16
uA
IDD
STBY1
LFCLK=LFOSC, STOPCLKSTBY=1,
RTC enabled
1.2 1.3 3.4 6.3 15.5
LFCLK=LFXT, STOPCLKSTBY=1,
RTC enabled
1.4 1.5 3.6 6.5 15.5
LFCLK=LFXT, STOPCLKSTBY=1,
GPIOA enabled
1.4 1.6 3.6 6.5 15.6
MSPM0G3507, MSPM0G3506, MSPM0G3505
SLASEX6A – FEBRUARY 2023 – REVISED JUNE 2023
www.ti.com
30 Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: MSPM0G3507 MSPM0G3506 MSPM0G3505
