Texas Instruments MSPM0G350 Series User Manual

Table 8-1. Supported Functionality by Operating Mode
OPERATING MODE
RUN SLEEP STOP STANDBY
SHUTDOWN
RUN0 RUN1 RUN2
SLEEP0 SLEEP1 SLEEP2
STOP0 STOP1 STOP2
STANDBY0 STANDBY1
Oscillators
SYSOSC EN EN DIS EN EN DIS OPT
(1)
EN DIS DIS DIS OFF
LFOSC or
LFXT
EN (LFOSC or LFXT) OFF
HFXT OPT DIS DIS OPT DIS DIS DIS DIS DIS DIS DIS OFF
SYSPLL OPT DIS DIS OPT DIS DIS DIS DIS DIS DIS DIS OFF
Clocks
CPUCLK 80 MHz 32 kHz 32 kHz DIS OFF
MCLK to PD1 80 MHz 32 kHz 32 kHz 80 MHz 32 kHz 32 kHz DIS OFF
ULPCLK to
PD0
40 MHz 32 kHz 32 kHz 40 MHz 32 kHz 32 kHz
4 MHz
(1)
4 MHz 32 kHz DIS OFF
ULPCLK to
TIMG0/8
40 MHz 32 kHz 32 kHz 40 MHz 32 kHz 32 kHz
4 MHz
(1)
4 MHz 32 kHz OFF
RTCCLK 32 kHz OFF
MFCLK OPT DIS OPT DIS OPT DIS OFF
MFPCLK OPT DIS OPT DIS OPT DIS OFF
LFCLK 32 kHz DIS OFF
LFCLK to
TIMG0/8
32 kHz OFF
LFCLK Monitor OPT OFF
MCLK Monitor OPT DIS OFF
PMU
POR monitor EN
BOR monitor EN OFF
Core regulator FULL DRIVE REDUCED DRIVE LOW DRIVE OFF
Core Functions
CPU EN DIS OFF
DMA OPT DIS (triggers supported) OFF
Flash EN DIS OFF
SRAM EN DIS OFF
PD1
Peripherals
CRC OPT DIS OFF
UART3 OPT DIS OFF
SPI0, SPI1 OPT DIS OFF
MATHACL OPT OFF
AES OPT OFF
MCAN0 OPT OFF
TIMA0, TIMA1 OPT OFF
TIMG6, TIMG7 OPT OFF
TIMG1,
TIMG12
OPT OFF
www.ti.com
MSPM0G3507, MSPM0G3506, MSPM0G3505
SLASEX6A – FEBRUARY 2023 – REVISED JUNE 2023
ADVANCE INFORMATION
Copyright © 2023 Texas Instruments Incorporated
Submit Document Feedback
53
Product Folder Links: MSPM0G3507 MSPM0G3506 MSPM0G3505
