PACKAGE OUTLINE
0.25
GAGE PLANE
0 -7
7.2
6.8
7.2
6.8
9.2
8.8
4X 5.5
44X 0.5
9.2
8.8
48X
0.27
0.17
1.6 MAX
0.5 MIN
1.45
1.35
0.75
0.45
LQFP - 1.6 mm max height
PT0048A
LOW PROFILE QUAD FLATPACK
4215159/A 12/2021
0.1 C
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. Reference JEDEC registration MS-026.
4. This may also be a thermally enhanced plastic package with leads conected to the die pads.
0.08 C A B
SEATING PLANE
SEE DETAIL
A
A15.000
DETAIL A
SCALE 2.000
A
B
C
