PACKAGE OUTLINE
C
48X
0.30
0.18
4.1 0.1
48X
0.5
0.3
1 MAX
(0.2) TYP
0.05
0.00
44X 0.5
2X
5.5
2X 5.5
B
7.15
6.85
A
7.15
6.85
VQFN - 1 mm max height
RGZ0048B
PLASTIC QUAD FLATPACK - NO LEAD
4218795/B 02/2017
PIN 1 INDEX AREA
0.08 C
SEATING PLANE
1
12
25
36
13 24
48
37
(OPTIONAL)
PIN 1 ID
0.1 C B A
0.05
EXPOSED
THERMAL PAD
49
SYMM
SYMM
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. The package thermal pad must be soldered to the printed circuit board for thermal and mechanical performance.
SCALE 2.000
