Chapter 1: Operating the TI-84 Plus Silver Edition 18
•
Horiz (horizontal) mode displays the current graph on the top half of the screen; it displays the
home screen or an editor on the bottom half (Chapter 9).
•
G-T (graph-table) mode displays the current graph on the left half of the screen; it displays the
table screen on the right half (Chapter 9).
MathPrint™, Classic
MathPrint™ mode displays most inputs and outputs the way they are shown in textbooks, such as
and .
Classic mode displays expressions and answers as if written on one line, such as 1/2 + 3/4.
Note: If you switch between these modes, most entries will be preserved; however matrix
calculations will not be preserved.
n/d, Un/d
n/d displays results as a simple fraction. Fractions may contain a maximum of six digits in the
numerator; the value of the denominator may not exceed 9999.
Un/d displays results as a mixed number, if applicable. U, n, and d must be all be integers. If U is a
non-integer, the result may be converted
U … n/d. If n or d is a non-integer, a syntax error is
displayed. The whole number, numerator, and denominator may each contain a maximum of three
digits.
Answers: Auto, Dec, Frac
Auto displays answers in a similar format as the input. For example, if a fraction is entered in an
expression, the answer will be in fraction form, if possible. If a decimal appears in the expression,
the output will be a decimal number.
Dec displays answers as integers or decimal numbers.
Frac displays answers as fractions, if possible.
Note: The Answers mode setting also affects how values in sequences, lists, and tables are
displayed. Choose
Dec or Frac to ensure that values are displayed in either decimal or fraction
form. You can also convert values from decimal to fraction or fraction to decimal using the
FRAC
shortcut menu or the
MATH menu.
GoTo Format Graph: No, Yes
No does not display the FORMAT graph screen, but can always be accessed by pressing
y ..
1
2
---
3
4
---+ x
2
xd
1
∫
