5-8-2. Remote mode deactivation procedure
A
V
W
W
CC:R
CV:G
OUTPUT
V(W) A(W)
MENU PROTECT CHECK
ESC/ KEY LOCK ENTER/MEM
1 2 3
DIGIT
PRESET/ SEQUENCE
* LOCK/RMT
STEP STOP PAUSE START
1
ESC/ KEY LOCK
* LOCK/RMT
PDS-A series
Operation procedure
When the unit is operated via external digital
control, the ESC/KEY LOCK key is lit in green
and the unit is remotely controlled.
When the unit is remotely controlled, you cannot
operate the keys and the rotary encoder.
1.
Press and hold the green-lit ESC/KEY LOCK
key. The light then goes out.
This returns the unit to local mode. You can
operate the keys and the rotary encoder after the
unit returns to local mode.
Even if the unit is in local mode, it returns to remote mode when it is operated via external digital control.
