11-1-4. Cable and connector settings
The circuits for all the connectors are open by default.
Adjust the connector settings according to the type of control used.
(1) When a GP-IB is used:
A commercially available GP-IB cable can be used for the GP-IB connection of IF-70GU. (our part No. CB-2420P)
When GP-IB is used, the settings of the IF-70GU connectors are as follows:
Connector
Circuit
CN2
Closed
CN3
Closed
CN4
Closed
(2) When a USB is used:
Use a commercially available USB full speed cable for the USB connection.
When a USB is used, the settings of the IF-71LU connectors are as follows:
Connector
Circuit
CN2
Closed
CN3
Closed
CN4
Open
(?) When a LAN is used
Use a commercially available LAN cable (category 5E or higher) to connect IF-71LU to a LAN.
When a LAN is used, the settings of the IF-71LU connectors are as follows:
Connector
Circuit
CN2
Closed
CN3
Closed
CN4
Closed
(3) When a RS-232C is used
Use commercially available crossover cables or interlink cables for the RS-232C connection.
The wiring of RS-232C cable is as follows:
Three lines are used: the sending, receiving, and grounding lines.
The hardware flow-control line is not used.
The wiring of the other terminals is disregarded.
PC / Sequencer
IF-70RS
D-Sub9 pin
Female
2
3
5
RxD
TxD
GND
TxD
RxD
GND
3
2
5
D-Sub9 pin
Female
When a RS-232C is used, the settings of the IF-70RS connectors are as follows:
Connector
Circuit
CN5
Closed
CN6
Open
CN7
Closed
CN8
Open
