11-3-10. Preset voltage setting (PREVOLT)
This command saves the set voltage directly to the preset memory, and queries the preset status.
Setting
PREVOLT x1,x2
x1: PRESET No. (1, 2, or 3)
x2: Set voltage value
Application example
PREVOLT 1,3.15
Saves 3.15V as the set voltage value in PRESET 1.
Query
PREVOLT? x1
x1: PRESET No. (1, 2, or 3)
Response form
PREVOLT x1,x2
x1: PRESET No. (1, 2, or 3)
x2: Set voltage value
Response example
PREVOLT 1,3.15
Indicates 3.15V is the set voltage value saved in PRESET 1.
Remarks
◆ For details about the setting range, see “Appendix C. SPECIFICATIONS”.
11-3-11. Preset current setting (PREAMP)
This command saves the set current directly to the preset memory, and queries the preset status.
Setting
PREAMP x1,x2
x1: PRESET No. (1, 2, or 3)
x2: Set current value
Application example
PREAMP 1,3.15
Saves 3.15A as the set current value for PRESET 1.
Query
PREAMP? x1
x1: PRESET No. (1, 2, or 3)
Response form
PREAMP x1,x2
x1: PRESET No. (1, 2, or 3)
x2: Set current value
Response example
PREAMP 1,3.15
Indicates 3.15A is the set current value saved in PRESET 1.
Remarks
◆ For details about the setting range, see “Appendix C. SPECIFICATIONS”.
11-3-12. Power monitor display setting(MONDSP)
This command changes the power monitor display.
Setting
MONDSP x1
x1: Monitor display setting
0: Voltage & current display
1: Voltage & power display
2: Power & current display
Application example
MONDSP 1
Sets the voltage & power display.
Query
MONDSP?
Queries the monitor display status.
Response example
MONDSP 0
0: Displays the voltage & current.
1: Displays the voltage & power.
2: Displays the power & current.
Remarks
11-3-13. Power-off display setting(DSPY)
This command sets the display for when the output is off.
Setting
DSPY x1
x1: Display change setting
0: Only set values are displayed while the output is off.
1: Display can be switched between the set values and output
values while the output is off.
Application example
DSPY 1
Specify whether the display can be switched between the set
values and output values while the output is off.
Query
DSPY?
Queries the display setting.
Response example
DSPY 0
0: Only set values are displayed while the output is off.
1: Indicates the display can be switched between the set/output
values while the output is off.
Remarks
