Thermal Dynamics CUTMASTER 60i Service Manual

CUTMASTER 60i
Manual 0-5475 SERVICE
5-41
Pressure Control Solenoid
After the cover is removed, you can access the Pressure Control Solenoid which is located on the inside of the power
supply and attached to the back of the input air filter. To replace, do the following:
1. Disconnect the two wires vis the presson connectors located below the tubing and on the side of the solenoid.
Pressure
Control
Solenoid
Remove these
two wires
Art # A-13312
2. Disconnect the two air line tubesfrom the fittings on the solenoid.
Pressure
Control
Solenoid
Remove these
two tubes
Art # A-13313
