Thinkware H100 - Hardwiring Cable for each Model

© 2016 THINKWARE. All rights reserved.
Confidential Restricted
F750, X500, X300, X150, H100, H50
F550
Hardwiring cable for each model
B+
ACC
GND
ACC
B+
GND
B+
ACC
GND
5
[Type A]
[TIP]
Current hardwiring cable’s type is A. (After2016.03)
But it will be changed to type B.
So when you install the hardwiring cable,
please double check which line is B+ or ACC by
checking tale of the each line.
[Type B]
