Basic operation test for the continuous power supply
1. Power on and continuous recording test
- After connecting the continuous power supply to the fuse box, ensure the power is on properly.
(While the terminal is connected, turn on the engine to ensure the dash cam is powered up properly.)
※ If the power is not on properly, then check that the GND, B+ wirings are connected properly.
2. Parking recording test
- After a continuous recording test, turn off the engine, and try to enter the parking recording mode.
※ If you cannot enter the parking recording mode, and the dash cam is turned off, then check the ACC wirings.
3. Wiring tester fuse test operation
B+ ACC GND
Engine Start ON → Buzzer sound
not heard
Metallic parts connected to the
frame.
[TIP}
You will hear no buzzer sound
during a B+/ACC test unless the
GND is connected.
14
