Thor Kitchen ARE30 - 1,200 watt single zone element LR, MR, RR locations

Component check
Thor Kitchen internal use only
1,200 watt single zone element
LR, MR, RR locations
Check element:
Checking at element directly:
Measure resistances between
terminals 2 & 4
Normal : 50Ω ± 5Ω
Checking from the infinite switch:
Remove the two blue wires at the
infinite switch. Measure resistance
between the two blue wire.
Normal: 50Ω ± 5 Ω
Checking HOT surface sensor
Remove two black wires from
sensor. Measure resistances
between L2 to K (x) Terminal
Normal: Under 165◦F = OL / OPEN
Above 165◦F = 1Ω or CL
Component
Test
Result
