Thor Kitchen ARE30 - Infinite switch (Dual zone element) LR and RR locations

Component check
Component
Test
Result
LF
RF
OFF
P1 to 2
Open
P2 to 4A
Open
Outer element
P1 to 2
Closed
P2 to 4A
Closed
Check Infinite switch : Check
1
With infinite switch in the HI
position for inner element measure
the resistances between Terminals
2 & P1
Normal : 1Ω or CLOSED
Abnormal : OL / OPEN
Check Infinite switch : Check
2
With infante switch in the HI
position measure the resistances
between terminal 4 & P2
Normal : 1 Ω or CLOSED
Abnormal : OL / OPEN
Infinite switch : Check 3
Set infinite switch to HI position for
the outer element. Measure
resistances between P2 & 4A
Normal: 1Ω or CLOSED
Abnormal: OL / OPEN
Inner element
P2 to 4
Open
P1 to 2
Open
Closed
Dual Zone
Infinite SW LOC
Knob position
Closed
Check point
P2 to 4
P2 to 4A
P2 to 4
Closed
Infinite switch
(Dual zone element)
LR and RR locations
Inner element
2
P2
S1
S2
S2
P1
4
S1
P2
4
2
P1
1 Ω
1 Ω
4A
4A
Outer element
1 Ω
P2
4A
