4 Programming (SDK)

113

4.2.6 Using Inputs and Outputs

Depending on the model, DCx Cameras have one or more digital inputs and outputs designed for

different purposes.

Input/output control: Here, you will find functions for setting the DCxCamera's I/Os and for using

the trigger and flash modes.

4.2.6.1 Input/Output Control

With these functions you can use the camera's digital in-/outputs for trigger and flash control.

is_SetExternalTrigger()

Enables the digital input for trigger operation or returns the

applied signal level.

is_IO()

Sets the digital output for flash control or a static output

level.

is_IO()

Sets the delay and power-on time of the flash output.

is_SetTriggerDelay()

Sets the trigger signal delay time.

is_IO()

Determines the delay and power-on times of the flash

output to obtain a global shutter effect when using rolling

shutter sensors.

is_ForceTrigger()

Simulates a trigger signal in hardware trigger mode.

With these commands you can activate additional functions or use GPIOs on some DCx Cameras.

is_IO()

Sets the additional digital outputs (GPIO).

is_IO()

Defines each port as a digital input or output (GPIO).

is_IO()

Toggles the color of the status LED for DCU22x and

DCC1240x cameras.
