5.1 Model Comparison
The following table outlines the key features of DCx camera series for direct comparison (see also
the DCx Camera Family chapter).
DCC1545M
DCC1645C
DCU223x
DCU224x
DC1240x
DC3240x
DC3260x
Sensor Type
CMOS
CCD
CMOS
CMOS
CMOS
Objective Mount
CS (C*)
C
C
C
C
EMC compliance
CE B
FCC B
CE A
FCC A
CE B
FCC A
CE A
FCC A
CE A
FCC A
WxHxD [mm]
(CCD size)
44 x 44 x 25.6
32 x 34 x 30.2
(37.2)
32 x 34 x 30.2
29 x 29 x 29
29 x 29 x 29
Mounting holes
bottom
top
side
1
0
0
2
3
3
2
3
3
2
3
3
2
3
3
Thread diameter
1/4" (#8-32,
M4)*)
#8-32, M4
#8-32, M4
1/4" (#8-32,
M4)*)
1/4" (#8-32,
M4)*)
Adjustable flange
back distance
+
-
-
-
-
IP protection class
30
30
30
30
30
Interface
USB 2.0
USB 2.0
USB 2.0
USB 3.0
USB 2.0
USB 3.0
USB 2.0
Power supply
USB
USB
USB
USB
USB
Lockable
connector
-
+
+
+
+
I/O connector
10-pin
connector
9-pin micro D-
SUB
9-pin micro D-
SUB
8-pin HR25
8-pin HR25
Optocoupler for I/O
-/-
1/1
1/1
1/1
1/1
Optocoupler speed
-
100 µs
100 µs
High (trigger)
High (trigger)
Max. cable length
(m)
5
5
5
5
5
Dig. I/O/GPIO
0/0/0
1/1/0
1/1/0
1/1/2
1/1/2
PWM
-
-
-
+
+
RS-232
-
-
-
+ (GPIO)
+ (GPIO)
I
2
C bus
-
-
-
-
-
Hot pixel correction
Software
Software
Software
Hardware
Hardware
Color calculation
Software
Software
Software
Hardware
Hardware
Hardware: Dig.
Subsampling/
Binning
-
-
-
+
+
Bit depth: Internal/
transferred
8/8
8/8
8/8
16/16
12/12
