THORLABS DCC1645C Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
221
4.3.33 is_GetAutoInfo
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_GetAutoInfo (HIDS hCam, UC480_AUTO_INFO* pInfo)
Description
Using the is_GetAutoInfo() function, you can query status information on the automatic image
control features. This information is written to the UC480_AUTO_INFO structure.
For further information on automatic control, please refer to the Automatic image control chapter.
Attention
The status information returned in the UC480_AUTO_INFO structure is only valid if at least one of the
auto control feature has been enabled using is_SetAutoParameter().
Input parameters
hCam
Camera handle
pinfo
UC480_AUTO_INFO structure (see below)
Contents of the UC480_AUTO_INFO Structure
INT
AutoAbility
Supported auto control features
AC_SHUTTER
Auto exposure shutter is supported
AC_SENSOR_SHUTTER
The sensor's internal auto exposure shutter
is supported
AC_FRAMERATE
Auto frame rate is supported
AC_SENSOR_FRAMERATE
The sensor's internal auto frame rate is
supported
AC_GAIN
Auto gain control is supported
AC_SENSOR_GAIN
The sensor's internal auto gain control is
supported
AC_SENSOR_AUTO_
CONTRAST_CORRECTION
Auto contrast correction for automatic
brightness control is supported
AC_SENSOR_AUTO_
CONTRAST_FDT_AOI
Use of face detection as field of view for
automatic brightness control is supported
AC_SENSOR_AUTO_
BACKLIGHT_COMP
Backlight compensation for automatic
brightness control is supported
AC_WHITEBAL
Auto white balance is supported
AC_SENSOR_WB
The sensor's internal auto white balance is
supported
AUTO_BRIGHT_STATUS
sBrightCtrlStatus
Status of automatic brightness control, see
below
AUTO_WB_STATUS
sWBCtrlStatus
Status of auto white balance, see below
DWORD
AShutterPhotomCaps
Returns a bit mask containing all supported
photometry settings (fields of view) for auto
