5.3.6 DCU224x
Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.31 Megapixel)
Aspect ratio
5:4
Bit depth
12 bits
Optical sensor class
1/2 inch
Exact sensitive area
5.952 x 4.762 mm
Exact optical sensor diagonal
7.62 mm (1/2.1 inch)
Pixel size
4.65 µm, square
Sensor name, monochrome
Sony ICX205AL
Sensor name, color
Sony ICX205AK
Gain
Monochrome model (master gain)
13.66x
Color model (master/RGB)
8.9/4.0x
Analog gain boost
2.0x (monochrome model only)
Camera timing
Pixel clock range (allowed/
recommended)
MHz
5 to 30 / 10 to 20
*1
Pixel clock for optimal image
quality
MHz
14
*1
Max. pixel clock with subsampling/
binning
MHz
30
*1
Frame rate (freerun mode)
fps
15.0
*2
Frame rate (trigger mode, 1 ms
exposure)
fps
17.0
*2
Exposure time in freerun mode
ms
0.066
*2
to 1360
*3
Exposure time in trigger mode
ms
0.066
*2
to 10 min
*3
AOI
Mode
Horizontal + Vertical
*4
AOI image width, step width
Pixels
16 to 1280, 4
Mono: AOI image height, step
width
Pixels
120 to 1024, 1
Color: AOI image height, step
width
Pixels
120 to 1024, 2
Mono: AOI position grid horizontal,
vertical
Pixels
1, 1
Color: AOI position grid horizontal,
Pixels
2, 2
