THORLABS DCC1645C Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging452
DCx Camera Functional Description and SDK Manual
vertical
AOI frame rate, 1024 x 768 pixels
(XGA)
fps
18
AOI frame rate, 640 x 480 pixels
(VGA)
fps
28
AOI frame rate, 320 x 240 pixels
(CIF)
fps
38
Binning
Mode
Vertical
*4
Method
V: Monochrome binning, additive
Factor
2x, 3x, 4x
Frame rate with 2x binning, 1280 x
512 pixels
fps
23
Frame rate with 3x binning, 1280 x
340 pixels
fps
28
Frame rate with 4x binning, 1280 x
256 pixels
fps
31
Subsampling
Mode
Vertical
*4
Method
V: Color subsampling
Factor
4x
Frame rate w/ 4x subsampling,
1280 x 256 pixels
fps
31
Hardware trigger
Mode
Asynchronous
Trigger delay with rising edge
µs
39.9 ±2.5
Trigger delay with falling edge
µs
57.7 ±2.5
Additive trigger delay (optional)
µs
15 µs...4 s
Power consumption
*5
W
1.1 to 2.1
*
1
The maximum possible pixel clock frequency depends on the PC hardware used.
*
2
Requires maximum pixel clock frequency.
*
3
Requires minimum pixel clock frequency.
*
4
Use of this function increases the frame rate.
*
5
The power consumption depends on the sensor model and the pixel clock setting.
Please see also the DCU224x Application Notes chapter.
Relative sensor sensitivity
