THORLABS DCC1645C Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
305
Example 1
/* Enable the last set LUT */
IS_LUT_ENABLED_STATE nLutEnabled = IS_LUT_ENABLED;
INT nRet = is_LUT(hCam, IS_LUT_CMD_SET_ENABLED, (void*) &nLutEnabled, sizeof(nLutEnabled));
Example 2
/* Force LUT and gamma to be included in software (former gamma behavior for cameras with USB3) */
IS_LUT_MODE nLutMode = IS_LUT_MODE_ID_FORCE_SOFTWARE;
INT nRet = is_LUT(hCam, IS_LUT_CMD_SET_MODE, &nLutMode , sizeof(nLutMode));
Example 3
/* Readout the current LUT state */
IS_LUT_STATE lutState;
INT nRet = is_LUT(hCam, IS_LUT_CMD_GET_STATE, (void*) &lutState, sizeof(lutState));
/* Readout the current LUT support information */
IS_LUT_SUPPORT_INFO lutSupportInfo;
nRet = is_LUT(hCam, IS_LUT_CMD_GET_SUPPORT_INFO, (void*) &lutSupportInfo, sizeof(lutSupportInfo));
Example 4
/* Set user-defined LUT */
IS_LUT_CONFIGURATION_64 userdefinedLUT;
...
... setze Werte in userdefinedLUT.dblValues[][] ...
...
INT nRet = is_LUT(hCam, IS_LUT_CMD_SET_USER_LUT, (void*) &userdefinedLUT, sizeof(userdefinedLUT));
Example 5
/* Readout of the set LUT */
/* User-defined LUT (without included gamma) */
IS_LUT_CONFIGURATION_64 userLUT;
INT nRet = is_LUT(hCam, IS_LUT_CMD_GET_USER_LUT, (void*) &userLUT, sizeof(userLUT));
/* Complet LUT (with included gamma) */
IS_LUT_CONFIGURATION_64 completeLUT;
nRet = is_LUT(hCam, IS_LUT_CMD_GET_COMPLETE_LUT, (void*) &completeLUT, sizeof(completeLUT));
Example 6
/* Set predefined LUT "Glow1" */
/* Firstly load GLOW1 */
IS_LUT_CONFIGURATION_PRESET_64 presetLUT;
presetLUT.predefinedLutID = IS_LUT_PRESET_ID_GLOW1;
INT nRet = is_LUT(hCam, IS_LUT_CMD_GET_PRESET_LUT, (void*) &presetLUT, sizeof(presetLUT));
/* Secondly set GLOW1 */
if (IS_SUCCESS == nRet)
{
nRet = is_LUT(hCam, IS_LUT_CMD_SET_USER_LUT, (void*) &presetLUT, sizeof(presetLUT));
}
Example 7
/* Load the "lutFile.xml" file and set LUT */
wchar_t* pFilename = L"lutFile.xml";
INT nRet = is_LUT(hCam, IS_LUT_CMD_LOAD_FILE, (void*) pFilename , NULL);
/* Save the current set LUT into the "lutFile2.xml" file */
wchar_t* pFilename2 = L"lutFile2.xml";
nRet = is_LUT(hCam, IS_LUT_CMD_SAVE_FILE, (void*) pFilename2 , NULL);
4.3.69 is_Measure
USB 2.0
USB 3.0
USB 2.0
USB 3.0
