5 Specifications
439
5.3.1 DCC3260x
Sensor specification
Sensor type
CMOS
Shutter system
Global shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
2 MP
Resolution
2.35 MPix
Resolution (h x v)
1936 x 1216 pixels
Aspect ratio
16:10
ADC (analog-to-digital converter)
12 bits
Optical sensor class
1/1,2 inch
Optical area
11.340 x 7.130 mm
Optical sensor diagonal
13.395 mm (1/1.19 inch)
Pixel size
5.86 µ m, square
Micro lens shift
0°
Manufacturer
Sony
Sensor name, monochrome
IMX249LLJ-C
Sensor name, color
IMX249LQJ-C
Special features
Supports overlap trigger mode for high
frame rates in trigger mode
Using the extended pixel clock
Gain
Monochrome model (master gain)
24x
Color model (master gain/RGB)
24x/4x
Analog gain boost
-
Camera timing
USB 3 uc480 CP Rev. 2
Pixel clock range
*1
MHz
30 – 118
Frame rate freerun mode
*2
fps
41
Frame rate trigger mode
(continuous)
*2
fps
41
Frame rate trigger mode
(maximum)
*2
fps
41
Exposure time (min
*2
, max
*3
)
ms
0.033 – 30 000
Maximum long exposure
ms
30 000
AOI
Mode
Horizontal + vertical
*4
AOI image width / step width
pixels
96 – 1936 / 8
AOI image height / step
width
pixels
2 – 1216 / 2
AOI position grid / horizontal,
vertical
pixels
8 / 2
Binning
Mode
-
