© 2016 Thorlabs Scientific Imaging306
DCx Camera Functional Description and SDK Manual
Syntax
INT is_Measure(HIDS hCam, UINT nCommand, void* pParam, UINT cbSizeOfParam)
Description
The function allows the measurement of the sharpness in a defined AOI of the current image. To
get a sharpness value the edges in the image are evaluated. The sharpness can only be indicated
as a relative value as it depends on the edges in the current image. An image with less edges will
reach the sharpness value of an image with a lot of edges.
The higher the value, the better the sharpness. The value can be used in comparative
measurements to detect changes in the image acquisition of the same object, e.g. caused by
readjusted lenses.
The nCommand input parameter is used to select the function mode. The pParam input parameter
depends on the selected function mode. If you select functions for setting or returning a value,
pParam contains a pointer to a variable of the UINT type. The size of the memory area to which
pParam refers is specified in the cbSizeOfParam input parameter.
Input parameters
IS_MEASURE_CMD_SHARPNESS_AOI_SET
Sets an AOI in which the sharpness is
measured. In the image are up to 5 AOIs
possible. These AOIs can also overlap.
(Example 1)
IS_MEASURE_CMD_SHARPNESS_AOI_INQUIRE
Returns information of the AOI, e.g. the
sharpness(Example 2)
IS_MEASURE_CMD_SHARPNESS_AOI_SET_PRESET
Sets different predefined AOIs in the image
(Example 3)
Pointer to a function parameter, whose function depends on
nCommand.
Size (in bytes) of the memory area to which pParam refers.
Content of the MEASURE_SHARPNESS_AOI_INFO structure
Relative sharpness value in the defined AOI
Position and size of the AOI:
s32X: X position
s32Y: Y position
s32Width: AOI width
s32Height: AOI height
Content of the MEASURE_SHARPNESS_AOI_PRESETS enumeration
IS_MEASURE_SHARPNESS_AOI_PRESET_1
Predefined AOI for the harpness measurement
(in each of the four image corner and in the
center)
Return values
