4 Programming (SDK)
307
IS_INVALID_PARAMETER
One of the submitted parameters is outside the
valid range or is not supported for this sensor or
is not available in this mode.
IS_NO_ACTIVE_IMG_MEM
No active image memory available. You must
set the memory to active using the
is_SetImageMem() function or create a
sequence using the is_AddToSequence()
function.
IS_NO_SUCCESS
General error message
IS_NOT_SUPPORTED
The camera model used here does not support
this function or setting.
IS_SUCCESS
Function executed successfully
Example 1
INT nRet = IS_SUCCESS;
/* Create info object */
MEASURE_SHARPNESS_AOI_INFO measureSharpnessInfo;
/* Set values of AOI_0: The position and size of the AOI equals the whole image */
measureSharpnessInfo.u32NumberAOI = 0;
measureSharpnessInfo.rcAOI.s32X = 0;
measureSharpnessInfo.rcAOI.s32Y = 0;
measureSharpnessInfo.rcAOI.s32Width = m_s32MaxImageWidth;
measureSharpnessInfo.rcAOI.s32Height = m_s32MaxImageHeight;
/* Set AOI_0 */
nRet = is_Measure(m_hCam, IS_MEASURE_CMD_SHARPNESS_AOI_SET, (void*)&measureSharpnessInfo,
sizeof(measureSharpnessInfo));
/* Set values of AOI_1 */
measureSharpnessInfo.u32NumberAOI = 1;
measureSharpnessInfo.rcAOI.s32X = 50;
measureSharpnessInfo.rcAOI.s32Y = 50;
measureSharpnessInfo.rcAOI.s32Width = 200;
measureSharpnessInfo.rcAOI.s32Height = 200;
/* Set AOI_1 */
nRet = is_Measure(m_hCam, IS_MEASURE_CMD_SHARPNESS_AOI_SET, (void*)&measureSharpnessInfo,
sizeof(measureSharpnessInfo));
Example 2
INT nRet = IS_SUCCESS;
/* Create info object */
MEASURE_SHARPNESS_AOI_INFO measureSharpnessInfo;
/* Get values of AOI_0 */
measureSharpnessInfo.u32NumberAOI = 0;
nRet = is_Measure(m_hCam, IS_MEASURE_CMD_SHARPNESS_AOI_INQUIRE, (void*)&measureSharpnessInfo,
sizeof(measureSharpnessInfo));
if (nRet == IS_SUCCESS)
{
UINT s32Sharpness = measureSharpnessInfo.u32SharpnessValue;
}
Example 3
