DCx Camera Functional Description and SDK Manual
exposure shutter, see below.
DWORD
AGainPhotomCaps
Returns a bit mask containing all supported
photometry settings (fields of view) for auto
gain control, see below.
DWORD
AAntiFlickerCaps
Returns a bit mask containing all supported
anti flicker settings for automatic control,
see below.
DWORD
SensorWBModeCaps
Returns a bit mask containing all supported
settings for the sensor's auto white balance,
see below.
DWORD
reserved[8]
Reserved space for extensions
Contents of the UC480_AUTO_INFO::AUTO_BRIGHT_STATUS Structure
INT
curValue
Current average brightness of the image (actual value); the
following rule applies independently of the image bit depth:
0 = black
255 = white
INT
curError
Current control deviation (error)
INT
curController
Current parameter value
AC_SHUTTER
Exposure time (shutter)
AC_GAIN
Gain
INT
curCtrlStatus
Current control status
ACS_ADJUSTING
Control is active.
ACS_FINISHED
Control is completed.
ACS_DISABLED
Control is disabled.
Contents of the UC480_AUTO_INFO::AUTO_WB_STATUS Structure
INT
curController
Current white balance control
AC_WB_RED_CHANNEL
Value of the red channel
AC_WB_GREEN_CHANNEL
Value of the green channel
AC_WB_BLUE_CHANNEL
Value of the blue channel
AUTO_WB_CHANNEL_STATUS
RedChannel
See AUTO_WB_CHANNEL_STATUS
AUTO_WB_CHANNEL_STATUS
GreenChannel
See AUTO_WB_CHANNEL_STATUS
AUTO_WB_CHANNEL_STATUS
BlueChannel
See AUTO_WB_CHANNEL_STATUS
Contents of the
UC480_AUTO_INFO::AUTO_WB_STATUS::AUTO_WB_CHANNEL_STATUS Structure
INT
curValue
Current average grayscale value (actual value)
INT
curError
Current control deviation (error)
INT
curCtrlStatus
Current control status
ACS_ADJUSTING
Control is active.
ACS_FINISHED
Control is completed.
ACS_DISABLED
Control is disabled.
